Tamiya 1/14 Man Tgx 26.540 6X4 Xlx Kit**
This is the Tamiya 56325 1/14 Man TGX 26.540 6X4 XLX Kit
This is a MAN Truck!
Also known as transporters that are used by F1 teams today, MAN Company's tractor truck the TGX 26.540 6x4 XLX was awarded "The 2008 Truck of the Year."Â This award winning truck comes reproduced as a 1/14 scale electric R/C model. The model features a ladder frame chassis with aluminum channels, suspension with metal leaf springs and friction dampers, and rear axles equipped with differentials. Providing this truck with a realistic scale finish are parts which feature two kinds of metal-plating and metal transfers to beautifully depict details such as the front grille's emblem. Furthermore, the chassis features a 3-speed transmission which allows gear shifting while driving via transmitter, with the sound and lighting actions reproduced by the separately available Multi Function Control (MFC-01) unit.
- Just like the actual vehicle, this model comes with large-sized curved side mirrors that feature two mirror surfaces.
- The left side exhaust cover is depicted with matt finished metal-plated part which features the MAN EURO 5 engrave.
- Both rear axles are equipped with differentials. The included coupler enables linkage with any of Tamiya's 1/14 scale R/C trailers.
- The TGX 26. 540 logos seen on both doors are depicted with metal transfers for greater scale presence.
- Included are metal transfers to depict the MAN logo and Lion emblem on the front grille.
- Both left and right step plates are depicted with matt finished metal-plated parts with realistic non-slip safe-guard sections.
The included 3 speed gearbox allows you to shift on the fly!
- Low (forwards and backwards)
- Medium (forwards and backwards)
- High (forwards and backwards)
Specifications:
- MFC-01 synchronizes the truck's light, sound, and vibration operation. Built-in ESC allows a low speed driving to enable connection to a trailer.
- 3-Speed Transmission allows gear shifts to be fully controlled during driving for added realism.
- Length 526mm, Width 193mm, Height 301mm, Weight (without options) Approx. 3.8kg
- Wheelbase 237+103mm
- Tread 156mm (Front), 138mm (Rear, Double Tire)
- Chassis: Aluminum & Polycarbonate Resin Ladder Frame
- Suspension: Front/Rear Leaf Springs
- Caster Angle (Front/Rear): 0°/0°
- Camber Angle (Front/Rear): 0°
- Toe Angle: 0°(Front & Rear)
- Dampers: Aluminum Dummy Dampers (Front & Rear)
- Drivetrain: Rear Double Axle Drive
- Transmission: 3-gear transmission (gear shifting operated via transmitter)
- Gear Ratio: (1st Gear) 32.49:1, (2nd Gear) 17.76:1, (3rd Gear) 10.66:1
- Diff. Gear: 3-bevel diff
- Motor: Type RS540
- Tire Width 22mm (Front & Rear)
- Tire Diameter 83mm (Front & Rear)
Required items (not included)
- Steering servo
- Shift servo (for changing gears)
- Remote controller - see below
- Battery
- Charger
- Paint - see below
- ESC (or the optional multi function unit)
- Optional: Tamiya semi truck multi function unit #56511
- Recommended Tools:
- Large Philips head screw driver
- Small Philips head screw driver
- Modelling knife
- Long nose pliers
- Side cutters
- Scissors
- Tweezers
- Plastic cement
- Instant cement
- Synthetic rubber cement
- File
